The working characteristics of the excavator
The operation of the hydraulic excavator is very complicated, often starts, accelerates, reverses, brakes, load changes greatly, wear and impact, and when working in the field,
the ambient temperature and geographical location change greatly, coupled with modern construction needs,
Our company mainly manufactures excavator chassis components, such as：Bottom Roller，Carrier Roller(Upper Roller), Idler，Loose Link，Lower Roller，Sprocket，Steel Track，
Top Roller，Track Chain，Track Group，Track Link，Track Pad，Track Shoe,if you are interesting our productct,pls contact with me(hongda04@qzhdm.com)
summarizing the excavator The requirements to be met are as follows:
(1) Ensure that the excavator boom, bucket, etc. can act independently, and at the same time cooperate with each other to perform multi-action work.
(2) The action of the working device and the rotation of the turntable can not only perform independent movement, but also produce compound movement to improve the working capacity of the excavator.
(3) The walking driving device of the crawler excavator is driven separately from the left and right, and it can work flexibly, independently and reliably in terms of slewing, walking and driving.
(4) Make each action of the excavator independent, and the speed change must be accurate.
(5) The work of the excavator must be safe and reliable, and the overload protection ability of each component must be strong;
Excavator hydraulic system should do:
(1) It has high transmission efficiency, realizes low fuel consumption, high utilization rate, and can provide large driving force;
(2) The overall components and key parts have sufficient reliability under the effects of large changes in ambient temperature and geographical location, frequent vibrations, and large impact forces.
(3) Reliable, portable, and shock-resistant coolers to control the total calorific value of the system. It is required that the temperature of the hydraulic oil should not exceed 60 degrees and the temperature rise should not exceed 45 degrees when the main engine continues to work.
(4) Since the working environment of the excavator has a lot of dust and other stolen goods, the pollution is serious and it is easy to be restricted. Therefore, the sealing performance of the hydraulic system should be good, and the practicability of each component should be strong, dustproof and reliable, and the hydraulic oil can be kept clean.
(5) Electro-hydraulic proportional control is adopted to realize remote or computer control. It can automatically detect system problems, solve them in time, and ensure the efficiency of work.
